224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯火力发电用打着机汽油性价比性好: 一流的汽油控住软件，特有的STC、ESTC 等级控住软件，特异开发的火塞顶部烧室，进行高压发射汽油，充沛雾化吸入，烧充沛。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电机组用起倾向瞬态性能参数成绩突出: 非凡的起倾向整个设计方案，相互配合康明斯显著的EFC系统的，调控要求高，回应时间段快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯生产发电用发起机升功效高: 整体布局设计方案紧凑型.外观简约时尚现场布置恰当，正常运作平静。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷机种 QSNT. QSK19. QSK38. QSK50实现在我国非城市道路3、时候及美国Tier2. Tier 3排放口规范标准要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备件管理必须得要性好， 打火机进行及维系皮肤保养便捷性，料工费低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

电机功率标准 Power Range   224-310KW结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L形态尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净效率 Dry Weight   940kg

224-310KW康明斯生产发电用打火机的优点和缺点：比热容小， 压缩的比低， 喷淋喷嘴新鲜空气预热，不易进行，移动式车机电原的好的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

汽车发驱动力材质	长用功效(kW)Prime Power	后备电源输出功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
